Description

REDMAGIC Astra Gaming Tablet — Basic Parameters

Dimensions & Design

• Height: 134.2 mm

• Width: 207 mm

• Depth: 6.9 mm

• Weight: 370 g

• Material: Metal middle frame + glass

• Colors: Starfrost (Silver), Eclipse (Black)

Memory & Storage

• Eclipse: 12 GB + 256 GB / 16 GB + 512 GB / 24 GB + 1 TB

• Starfrost: 12 GB + 256 GB / 16 GB + 512 GB

• RAM: LPDDR5T

• Storage: UFS 4.1 Pro

Display

• Size: 9.06-inch OLED

• Resolution: 2,400 × 1,504 (2.4K)

• Refresh Rate: Up to 165 Hz

• Touch Sampling: 2,000 Hz (single-finger), 240 Hz (multi-finger)

• Pixel Density: 313 PPI

• Brightness: 1,600 nits peak / 1,100 nits full-screen

• Aspect Ratio: 16:10

• Color Gamut: DCI-P3

• Color Accuracy: ΔE ≈ 0.7 (Golden)

• Glass: Corning® Gorilla® Glass

• Certifications: SGS Eye Protection

• Durability: IP54 splash, water, and dust resistant

Cooling System — Enhanced ICE-X

• Under-screen cooling alloy

• Under-screen high-conductivity graphene & copper foil

• Under-screen vapor chamber

• Motherboard copper foil + vapor chamber

• High-thermal-conductivity gel

• Liquid Metal 2.0

• Turbo Fan (20,000 RPM)

• Durable aluminum alloy mid-frame

• Additional graphene & copper layers

Hardware & Performance

• Processor: Snapdragon 8 Elite (4.32 GHz Oryon™ CPU + Adreno™ GPU)

• Coprocessor: RedCore R3 Pro

Connectivity

• Wi-Fi: 802.11 a/b/g/n/ac/ax

• Bluetooth: 5.4

• HDMI: Via converter

• DisplayPort: 2K HD video output

• Port: USB-C (USB 3.2 Gen 2, DisplayPort, Fast Charging)

Cameras

• Rear: 13 MP, AI-enhanced, 5P lens, 4K@30fps video

• Front: 9 MP, 4P lens, 1080p@30fps, world’s smallest φ1.9 mm front cam

Sensors

• Fingerprint sensor

• Electronic compass

• Gyroscope

• Ambient light sensor

• Accelerometer

Software

• OS: REDMAGIC OS 10.5 (based on Android 15)

Battery & Charging

• Capacity: 8,200 mAh dual-cell

• Quick Charge: Supported

• Charge Bypass: Supported

• Charger: Not included in box

Audio & Haptics

• Speakers: Stereo dual 1620 speakers

• Certification: DTS:X® Ultra, Snapdragon Sound

• Haptics: Dual 0815 X-axis linear motors

• Formats Supported: WAV, AAC, MP3, FLAC, MP4, MKV, WEBM, JPEG, PNG, HEIC, and more

• Video Decoding: Up to 8K @ 60fps

Special Features

• Magic Key: Default GameSpace launcher; customizable for shortcuts (camera, flashlight, mute, translation, etc.)

• RGB Lighting: Fully customizable effects

In the Box

• REDMAGIC Astra Gaming Tablet ×1

• Type-C Cable ×1

• User Manual ×1

• Logo Sticker ×1

• Note: Charger not included
